Special series for outdoor applications,
Quick disassembly threaded mouth and bayonet cup,
Full traffic port,
Lightweight, miniaturized, reducing installation space,
The pressure gauge can be either an embedded or external pressure circular gauge,
Use locking adjustment screws to protect the set value,
Whole metal shell,
Two temperature difference options are available for low-temperature environments,
The adjusting rod is made of stainless steel material.
| Model | RGA(S)-02 | RGA(S)-03 | RGA(S)-04 | RGA(S)-06 | RGA(S)-08 | |||||||||||
| Piping Size | 1/4" | 3/8" | 1/2" | 3/4" | 1" | |||||||||||
| Using fluids | Compressed air | |||||||||||||||
| Pressure regulating structure | Diaphragm type | |||||||||||||||
| Body Material | Aluminum alloy/stainless steel | |||||||||||||||
| Cup material | Aluminum alloy/stainless steel | |||||||||||||||
| Pressure gauge material | Stainless steel | |||||||||||||||
| Filter core material | PE (standard equipment) copper (optional) | |||||||||||||||
| Filtration | 5 μ m (standard equipment) 40 μ m (optional) | |||||||||||||||
| Operating Pressure | 0.05~0.85Mpa | |||||||||||||||
Ambient temperature | Room temperature -10 ℃~65 ℃ (the water cup is made of PC material and can be equipped with a cover) | |||||||||||||||
| Low temperature -40 ℃ (water cup made of aluminum alloy material) | ||||||||||||||||
| When the temperature is below+2 ℃, the gas source must be sufficiently dry to prevent freezing | ||||||||||||||||
